Features
• Wideband, 30 to 6000 MHz
• Low insertion loss, 1.5 dB typ. up to 4 GHz
• Good amplitude unbalance, ±0.4 dBtyp.
• Good input return loss, 15 dB typ.
• Low phase unbalance, ±4˚ typ.
• 50Ω 10 to 6000 MHz

Applications
• PCS
• wideband push-pull amplifiers
• cellular
