Features
• Low passband IL , 2.2 dB typ.
• Fast Rejection roll-off
• Excellent rejection floor, 80 dB typ.
• Wider stopband performance up to 5GHz
• Good Return loss, 18 dB typ.
• Rugged Metal package
• Gross Leak Sealed

Applications
• Defense systems
• Transmitters and receivers

Maximum Ratings
Operate Temperature -40°C to 85°C
Storage Temperature -55°C to 100°C
RF Power Input 5W max. @25°C
