Features
• linear phase, up to ±8deg typ. @ Fc ±30MHz
• good VSWR, 1.2:1 typ. @ passband
• small size 0.35″ x 0.35″
• shielded case
• aqueous washable

Applications
• harmonic rejection
• transmitters / receivers

Maximum Ratings
Operating Temperature -40°C to 85°C
Storage Temperature -55°C to 100°C
RF Power Input 0.5W at 25ºC
Permanent damage may occur if any of these limits are exceeded.
