Moca Low Pass Filter-1.2GHz

$0.00

Features:
⚫ Suitable for MoCA, CATV, Cable net and other communication systems
⚫ Frequency Range 5MHz -1.2GHz,5MHz -3GHz
⚫ Regulatory Compliance CE, RoHS
⚫ UV Resistant Label
⚫ Robust Compact Design
⚫ Excellent RFI Shielding
⚫ Standard “F” Type Male-Female Connectors
⚫ 7/16″ hex head for convenience of installation
⚫ Waterproof at both ends to standards (15psi)
⚫ Class A RFI Shielding
⚫ SMD, High Stability,High Rejection,Low Loss Excellent Return Loss

SKU: Low Pass Filter Categories: ,

Description

Prices and sales term are subject to our final confirmation

Prevent interference to and from neighboring home point-of-entry filter. Universal standard for home entertainment networking. The ECO-Broadband MoCA low-pass point-of-entry filter (LBMLPF) is used at the subscriber entry to prevent interference the input of the device going into the home, this Tough filter isolated adjacent subscribers from each other by 70-100dB when the filter is deployed at each drop.
